KC Thermocouple Compensating Cable


Type K Thermocouple Compensating Cable – KC

Red Compensating Cable – KC
compensating cable

– PVC double insulated
– Materials : 2 x 13/0.2mm Copper/Constantan
– Max Working Temperature : (-25 ~ 105°C)
–Standard: Conforms to: ASTM E230-1993,  ISA MC96.1-1982,  IEC 584-3:1989. mod,  IEC 584-2:1982, IEC 584-2:1982
– Jacket Colour : Outer : Red, Green
.                                 Inner : Blue +White / Green +white
Packing: come in 100m/roll





Compensating Cable in Green

Green Compensating Cable – KC

– PVC double insulated
– Materials : 2 x 13/0.2mm Copper/Constantan
– Max Working Temperature : (-25 ~ 105°C)
–Standard: Conforms to: ASTM E230-1993,  ISA MC96.1-1982,  IEC 584-3:1989. mod,  IEC 584-2:1982, IEC 584-2:1982
– Jacket Colour : Outer : Red, Green
.                                 Inner : Blue +White / Green +white
Packing: come in 100m/roll
